SMART on FHIR demo

SMART on FHIR demo

Note: this cell has custom styling that makes it not show up in the Voilà Dashboard. You can hide any other markdown in this notebook by surrounding it with the same “demo-info” class ID as this one.

This dashboard relies on credentials loaded from SMART app launch via the jupyter-smart-on-fhir extension.

(DEMO) To edit the dashboard:

  1. click here to open the notebook

  2. edit the notebook

  3. save changes

  4. reload this page

To add goals to the demo, add include_goal=True to the last cell in this notebook to select a patient, edit the cell below that sets patient_id , study_id. You can see values in the JupyterHealth Exchange Portal.

import os

import ipywidgets as W
from IPython.display import HTML, Image, Markdown, display


# Convenience function to display markdown
def md(s):
    display(Markdown(s))


# Use "if not VOILA:" blocks to print debug/private output
# Otherwise all output is by default shown by VOILA
VOILA = os.environ.get("VOILA_REQUEST_URL")
from jupyterhealth_client import Code, JupyterHealthClient

client = JupyterHealthClient()
BLOOD_PRESSURE = Code.BLOOD_PRESSURE.value
user_info = client.get_user()
import json
import os
from pathlib import Path

import requests

token_file = Path(os.environ["SMART_TOKEN_FILE"])
with token_file.open() as f:
    token_info = json.load(f)
    smart_config = token_info["smart_config"]
    fhir_url = token_info["fhir_url"]
    token_response = token_info["token"]
    fhir_token = token_response["access_token"]

fhir = requests.Session()
fhir.headers = {"Authorization": f"Bearer {fhir_token}"}
practitioner = fhir.get(fhir_url + token_response["profile"]["reference"]).json()
if not VOILA:
    practitioner
fhir_patient = fhir.get(fhir_url + f"Patient/{token_response['patient']}").json()
if not VOILA:
    fhir_patient
def _fmt_name(res: dict):
    name = res['name'][0]
    given = " ".join(name['given'])
    return f"{given} {name['family']}, id: {res['id']}"


md(f"""

#### SMART credentials

**Practitioner**: {_fmt_name(practitioner)}

**Patient**: {_fmt_name(fhir_patient)}
""")
def get_patient_by_external_id(external_id: str) -> dict:
    """Get a single patient by external id

    For looking up the JHE Patient record by an external (e.g. EHR) patient id.
    """

    # TODO: this should be a single lookup, but no API in JHE yet
    for patient in client.list_patients():
        if patient['identifier'] == external_id:
            return patient
    raise KeyError(f"No patient found with external identifier: {external_id!r}")


patient = get_patient_by_external_id(fhir_patient["id"])
patient_id = patient["id"]
_width = "500px"

study_id = 30013

patient_df = client.list_observations_df(
        patient_id=patient_id, study_id=study_id, code=Code.BLOOD_PRESSURE
    )
if not VOILA:
    if patient_df is None or not len(patient_df):
        raise ValueError("Found no observations!")
    display(patient_df.head())
# now start the plotting

from datetime import timedelta
from enum import Enum
from functools import partial
from itertools import chain

import altair as alt
import pandas as pd

pd.options.mode.chained_assignment = None


class Goal(Enum):
    """Enum for met/unmet

    These strings will be used for the legend.
    """

    met = "under"
    unmet = "over"


class Category(Enum):
    normal = "normal"
    elevated = "elevated"
    hypertension = "hypertension"


def classify_bp(row):
    """Classify blood pressure"""
    # https://www.heart.org/en/health-topics/high-blood-pressure/understanding-blood-pressure-readings
    # note from : We can decide to have just normal, elevated and hypertension to begin with
    if (
        row.diastolic_blood_pressure_value < 80
        and row.systolic_blood_pressure_value < 120
    ):
        return Category.normal.value
    elif (
        row.diastolic_blood_pressure_value < 80
        and 120 <= row.systolic_blood_pressure_value < 130
    ):
        return Category.elevated.value
    else:
        return Category.hypertension.value


def bp_goal(patient_df, goal="140/90"):
    """True/False for blood pressure met goal"""
    sys_goal, dia_goal = (int(s) for s in goal.split("/"))
    if (patient_df.systolic_blood_pressure_value <= sys_goal) & (
        patient_df.diastolic_blood_pressure_value <= dia_goal
    ):
        return Goal.met.value
    else:
        return Goal.unmet.value


red_yellow_blue = [
    "#4a74b4",
    "#faf8c1",
    "#d4322c",
]
red_blue = [red_yellow_blue[0], red_yellow_blue[-1]]


def bp_over_time(bp, color_scale="category"):
    """Plot blood pressure over time"""
    # https://vega.github.io/vega/docs/schemes/#redyellowblue
    if color_scale == "category":
        domain = [
            Category.normal.value,
            Category.elevated.value,
            Category.hypertension.value,
        ]
        color = alt.Color(
            "category:O",
            scale=alt.Scale(
                domain=domain,
                range=red_yellow_blue,
            ),
        )
        shape = alt.Shape(
            "category:O",
            scale=alt.Scale(
                domain=domain,
            ),
        )
    elif color_scale == "goal":
        domain = [Goal.met.value, Goal.unmet.value]
        color = alt.Color(
            "goal:O",
            scale=alt.Scale(domain=domain, range=red_blue),
        )
        shape = alt.Shape(
            "goal:O",
            scale=alt.Scale(domain=domain),
        )

    # heuristic for x-ticks
    end_time = bp.effective_time_frame_date_time.max()
    end_date = end_time.date()
    start_date = bp.effective_time_frame_date_time.min().date()
    time_frame_days = (end_date - start_date).total_seconds() / (3600 * 24)
    axis_args = {"format": "%Y-%m-%d"}
    if time_frame_days < 7:
        # minimum of one week
        start_date = end_date - timedelta(days=7)
    if time_frame_days < 14:
        # at least a week
        axis_args["tickCount"] = dict(interval="day", step=1)
    if 14 <= time_frame_days < 30:
        # expand less than a month to 1 month
        start_date = end_date - timedelta(days=30)
    if time_frame_days > 90:
        # at least a few months, label with year-month
        axis_args["format"] = "%Y-%m"

    x = alt.X(
        "effective_time_frame_date_time_local",
        title="date",
        axis=alt.Axis(
            labelAngle=30,
            **axis_args,
        ),
        scale=alt.Scale(
            domain=[
                pd.to_datetime(start_date),
                pd.to_datetime(end_date + timedelta(days=1)),
            ]
        ),
    )

    charts = [
        [
            alt.Chart(bp, title="blood pressure")
            .mark_line(color="#333")
            .encode(
                x=x,
                y=alt.Y(f"{which}_blood_pressure_value", title="mmHg"),
            ),
            alt.Chart(bp, title="blood pressure")
            .mark_point(filled=True)
            .encode(
                x=x,
                y=alt.Y(f"{which}_blood_pressure_value", title="mmHg"),
                color=color,
                shape=shape,
                tooltip=[
                    alt.Tooltip("effective_time_frame_date_time_local", title="date"),
                    alt.Tooltip("systolic_blood_pressure_value", title="Systolic"),
                    alt.Tooltip("diastolic_blood_pressure_value", title="Diastolic"),
                    alt.Tooltip("category"),
                ],
            ),
        ]
        for which in ("systolic", "diastolic")
    ]
    return alt.layer(*chain(*charts))


def bp_by_tod(bp):
    """Plot blood pressure by time of day"""
    tod_tooltip = [
        alt.Tooltip(
            "mean(diastolic_blood_pressure_value):Q",
            title="avg diastolic",
            format=".0f",
        ),
        alt.Tooltip(
            "mean(systolic_blood_pressure_value):Q", title="avg systolic", format=".0f"
        ),
        alt.Tooltip("count(diastolic_blood_pressure_value)", title="measurements"),
        alt.Tooltip("hours(effective_time_frame_date_time_local)", title="hour"),
    ]
    charts = [
        alt.Chart(bp, title="by time of day")
        .mark_line(point=True)
        .encode(
            x=alt.X(
                "hours(effective_time_frame_date_time_local)",
                title="time of day",
                scale=alt.Scale(domain=[0, 24]),
            ),
            y=alt.Y(
                f"mean({which}_blood_pressure_value):Q",
                title=which,
                axis=alt.Axis(title=""),
            ),
            tooltip=tod_tooltip,
        )
        for which in ("systolic", "diastolic")
    ]
    return alt.layer(*charts)


def plot_patient_blood_pressure(patient_df, goal="140/90", color_scale="category"):
    """plot blood pressure, given a patient data frame, as returned by get_patient_data"""
    bp = patient_df.loc[patient_df.resource_type == BLOOD_PRESSURE]
    bp["category"] = bp.apply(classify_bp, axis=1)
    bp["goal"] = bp.apply(partial(bp_goal, goal=goal), axis=1)
    return (
        (bp_over_time(bp, color_scale=color_scale) | bp_by_tod(bp))
        .resolve_scale(y="shared", color="independent", shape="independent")
        .configure_point(size=100)
        .interactive()
    )


if not VOILA:
    # show last 30 days of data
    end_date = patient_df.effective_time_frame_date_time.max()
    display(
        plot_patient_blood_pressure(
            patient_df[patient_df.effective_time_frame_date_time >= (end_date - timedelta(days=30))],
            color_scale="goal",
        )
    )
def bp_category_style(row):
    """highlight rows by bp category"""
    category = Category(row.category)
    if category == Category.hypertension:
        color = "#fdd"
    elif category == Category.elevated:
        color = "#ffc"
    else:
        color = None

    return [f"background-color:{color}" if color else None] * len(row)


def bp_goal_style(row):
    """highlight rows by bp category"""
    goal = Goal(row.goal)
    if goal == Goal.unmet:
        color = "#fdd"
    else:
        color = None

    return [f"background-color:{color}" if color else None] * len(row)


def bp_goal_fraction(patient_df, goal="140/90"):
    bp = patient_df.loc[patient_df.resource_type == BLOOD_PRESSURE]
    sys_goal, dia_goal = (int(s) for s in goal.split("/"))
    met_goal = (bp.systolic_blood_pressure_value <= sys_goal) & (
        bp.diastolic_blood_pressure_value <= dia_goal
    )
    return met_goal.sum() / len(bp)


def bp_table_info(patient_df, goal="140/90", color_scale="category"):
    """Display tabular info"""
    bp = patient_df.loc[
        patient_df.resource_type == BLOOD_PRESSURE,
        [
            "effective_time_frame_date_time_local",
            "systolic_blood_pressure_value",
            "diastolic_blood_pressure_value",
        ],
    ]
    bp["category"] = bp.apply(classify_bp, axis=1)
    bp["goal"] = bp["goal"] = bp.apply(partial(bp_goal, goal=goal), axis=1)
    # relabel columns
    bp.columns = ["date", "systolic", "diastolic", "category", "goal"]
    bp["time"] = bp.date.dt.time
    bp["date"] = bp.date.dt.date
    bp = bp.astype({"systolic": int, "diastolic": int})

    label_style = {"font_weight": "bold", "font_size": "150%"}

    table = W.Output()
    with table:
        styled = (
            bp.style.hide()
            .hide(["category", "goal"], axis="columns")
            .format({"time": "{:%H:%M}"})
        )
        if color_scale == "goal":
            styled = styled.apply(bp_goal_style, axis=1)
        else:
            styled = styled.apply(bp_category_style, axis=1)
        display(HTML(styled.to_html(index=False)))

    summary = W.Output()
    min_idx = bp.systolic.idxmin()
    max_idx = bp.systolic.idxmax()
    summary_table = pd.DataFrame(
        {
            "systolic": [
                bp.systolic.min(),
                bp.systolic.max(),
                bp.systolic.mean(),
            ],
            "diastolic": [
                bp.diastolic.min(),
                bp.diastolic.max(),
                bp.diastolic.mean(),
            ],
            "date": [
                bp.loc[min_idx].date,
                bp.loc[max_idx].date,
                "-",
            ],
        }
    )
    summary_table = summary_table.astype({"systolic": int, "diastolic": int})
    summary_table.index = pd.Index(["min", "max", "avg"])
    with summary:
        display(HTML(summary_table.to_html()))

    # calculate goal fraction
    at_goal_fraction = bp_goal_fraction(patient_df, goal)
    overview = W.Output()
    with overview:
        display(
            HTML(f"<div style='font-size: 250%'>at goal: {at_goal_fraction:.0%}</div>")
        )

    box_layout = {
        "border_left": "1px solid #aaa",
        "padding": "8px",
        "margin": "8px",
    }
    right_box = [
        W.Label(value="summary", style=label_style),
        summary,
    ]
    if color_scale == "goal":
        right_box.extend(
            [
                W.Label(value="overview", style=label_style),
                overview,
            ]
        )
    layout = W.HBox(
        [
            W.VBox(
                [W.Label(value="Measurements", style=label_style), table],
                layout=box_layout,
            ),
            W.VBox(
                right_box,
                layout=box_layout,
            ),
        ]
    )
    layout.layout.justify_content = "flex-start"
    return layout


if not VOILA:
    # preview while run interactively (not voila)
    display(bp_table_info(patient_df[-100:], color_scale="goal"))
import time


def plot_patient(
    view=30,
    comorbidity=False,
    color="goal",
):
    if comorbidity:
        goal = "130/80"
    else:
        goal = "140/90"
    df = patient_df
    if df is None:
        if not patient_id:
            md("## No patient selected!")
            return

        if not study_id:
            md("## No study selected!")
            return

        consents = client.get_patient_consents(patient_id)
        md_lines = [f"## No data for patient {patient_id} in study {study_id}!", ""]

        md_lines.append("Study consents:")
        for study in consents["studies"]:
            md_lines.append(f"  - [{study['id']}] {study['name']}")
        if not consents["studies"]:
            md_lines.append("- (none)")
        md_lines.append("")

        md_lines.append("Studies pending consent:")
        md_lines.append("")
        for study in consents["studiesPendingConsent"]:
            md_lines.append(f"  - [{study['id']}] {study['name']}")
        if not consents["studiesPendingConsent"]:
            md_lines.append("- (none)")
        md_lines.append("")
        md("\n".join(md_lines))
        return

    last_day = df.effective_time_frame_date_time.dt.date.max()
    start_date = last_day - timedelta(days=view)
    df = df[df.effective_time_frame_date_time.dt.date >= start_date]
    # for demo: scale if current user is too healthy
    df = df.copy()
    df["systolic_blood_pressure_value"] = (df["systolic_blood_pressure_value"]).astype(
        int
    )
    df["diastolic_blood_pressure_value"] = (
        df["diastolic_blood_pressure_value"]
    ).astype(int)
    display(plot_patient_blood_pressure(df, goal=goal, color_scale=color))
    display(bp_table_info(df, goal=goal, color_scale=color))
    # utterly bizarre: voilá hangs if this returns too quickly
    time.sleep(0.5)


if not VOILA:
    plot_patient()

Everything above here is setup of the demo itself, not part of the demo; this would all be hidden and managed by EHR inputs.

Below here is the actual demo that is meant to show up as a dashboard and meant for display.

# create the interactive chart


def create_dashboard(include_goal=False):
    """
    Create the dashboard

    only one input: include_goal
    if True, include UCSF goal inputs ('after' view)
    if False, only include American Heart Association category view
    """

    interact_args = {}
    if include_goal:
        comorbidity_widget = W.Checkbox(
            description="Any comorbidities: ASCVD > 10%, Diabetes Mellitus, CKD (EGFR 20-59), Heart Failure"
        )
        comorbidity_widget.layout.width = "100%"
        comorbidity_widget.add_class("added-widget")
        color_widget = W.Dropdown(
            value="goal", options={"UCSF Goal": "goal", "AHA Category": "category"}
        )
        color_widget.add_class("added-widget")
        interact_args["comorbidity"] = comorbidity_widget
        interact_args["color"] = color_widget
    else:
        interact_args["comorbidity"] = W.fixed(False)
        interact_args["color"] = W.fixed("category")

    dashboard = W.interactive(
        plot_patient,
        view={
            "Week": 7,
            "Month": 30,
            "Year": 365,
        },
        **interact_args,
    )
    # give it some border to set it off from the demo setup
    dashboard.layout.border = "4px solid #cff"
    dashboard.layout.padding = "16px 30px"

    # rerender on change of widgets outside the interact
    return dashboard

Agile Metabolic JupyterHealth Dashboard

# DEMO: uncomment include_goal=True to add UCSF goals to visualization,
create_dashboard(
    include_goal=True,
)
# weird: displaying this in a Markdown cell
# causes voila to hang (?!)
display(Image(url="https://jupyterhealth.org/images/PoweredByJupyter.png"))
